Choosing a mains fencing energiser

Choosing a mains fencing energiser

A Rough Guide To determine which Energiser (Length of fence x the number of lines of tape/wire) + at least 50% for future expansion.


Use a stronger Energiser when containing or excluding animals which are well insulated (such as sheep, rabbits, birds). Similarly, it is advisable to choose a stronger Energiser for energising power hungry Electric Netting as the netting can easily touch vegetation, which causes earthing and power loss.


It is always preferable to trade up in energisers and be ready for the future. WARRANTY: Our aim is to offer VALUE FOR MONEY and to supply good quality and reliable products at the right price. All our Energisers have a two-year warranty. For reliability choose a Mains or Solar Energiser rather than a battery Energiser if practical, as your system will only be as good as your batteries.


To help you make a short list of energisers to choose from:

1. Refer to the area-distance guide below to help work out roughly how long your electric fence will be. This will give you a single line distance.

Example: If you have a 5 Acre (2.02 Hectare) area to fence, you will see from the guide that your single line would be approximately 600 metres long (i.e 100+200+100+200 = 600)

2. Next you will need to multiply this single line distance by the number of horizontal lines you wish to install. For electrified netting you need to multiply this distance by the total number of horizontal strands.

Example 1: A typical electric fence is made up of three horizontal lines, therefore using the earlier example of a 600 metre fence line you would have a total distance requirement of 1800 metres or 1.8 Kilometres (i.e. 3 x 600m = 1800m).

Example 2: A typical electrified sheep net has 8 horizontal strands lines, therefore a for a 600 metre fence line you would have a total distance requirement of 4800 metres or 4.8 Kilometres (i.e. 8 x 600m = 4800m).


3. Now, staying with our above examples, you can refer to the table below to determine which energiser will support an electric fence up to or over either 1.8 Kilometres or 4.8 Kilometres in length.


Energiser Stored Energy Recommended Max' Single Line Distance
HLC40 Gemini 0.4 joules 4.0 Kilometres
HLC80 Gemini 0.8 joules 8.0 Kilometres
HLC120 Gemini 1.2 joules 12 Kilometres
HLM200 Horsepower 2.4 joules 20 Kilometres
P100 EAGLE - Discontinued 2007 use HLC120 0.9 joules 10 Kilometres
P100S SUPER EAGLE 2.5 joules 25 Kilometres
PHOENIX HLM350 3.5 joules 30 Kilometres
HLM400 CONDOR 3.4 joules 30 Kilometres
HLM600 PEREGRINE 5.6 joules 40 Kilometres
PHOENIX HLM700 7.0 joules 50 Kilometres
PHOENIX HLM1200 12.0 joules 60 Kilometres
PHOENIX HLX1500 12.0 - 18.0 joules 60 Kilometres


For more information about the features and benefits of the mains energiser, read the article 'Mains Energisers Features and Benefits'.
